Waveshare Infrared Reflective Sensor, IR

£4.99 GBP

Разпродажба Изчерпано

С включени данъци. Доставката се изчислява при плащане.

Option IR

Overview
1. Reflective infrared Transceiver
2. Features wide range voltage comparator LM393
3. Adjustable sensitivity
4. Signal output indicator

Specifications
1. Power: 3.0V ~ 5.3V
2. Dimension: 25mm * 15.9mm
3. Mounting holes size: 2.0mm

Applications
1. Robot path tracking
2. Obstacle-avoiding car
3. Pipeline counter

How to Use
In the case of working with a MCU:
Pinouts
1. VCC: 3.0V ~ 5.3V
2. GND: Power supply ground
3. AOUT: MCU.IO (analog output)
4. DOUT : MCU.IO (digital output)

Package Contents
1. Infrared Reflective Sensor x1
2. 4-pin custom connector jumper wire x1

Specification:

Package Weight

One Package Weight

0.01kgs / 0.02lb

One Package Size

5cm * 3cm * 1cm / 1.97inch * 1.18inch * 0.39inch

Qty per Carton

6240

Carton Weight

15.00kgs / 33.07lb

Carton Size

60cm * 39cm * 40cm / 23.62inch * 15.35inch * 15.75inch
